Description

Product details

Operational Range Pressure : Up to 150 bar. Temperature : -50 TO 200°C Shaft Speed :20 m/s Shaft diameter : 25 mm TO 200 mm Seal Faces : Carbon, Silicon Carbide, Tungsten Carbide, Ceramic, Lecrolloy. Elastomers : Viton, Silicon, EPDM, PTFE, GFT, Teflon Encapsulated Viton MOC : SS-304, SS-316, Alloy-20, Hastelloy-C, Monel, Titanium. Applications : Used to handle high pressure, high temperature, high acidic, corrosive, toxics and gas emitting products in equipment's like reactors used in chemical and bulk drug manufacturing, agitators, mixers, blowers in Drug & pharmaceuticals, food processing industry. We offer FGT-AG Series high single/double/high pressure/dry run agitator seals which are outside mounted balanced seal which won’t require shaft or sleeve step its specially designed to handle high pressure, high temperature, high acidic, corrosive, toxics fluids, This seals are supplied in cartridge condition, pre-assembled and pre-set to required working dimensions which can be slide on the shaft and bolted to the vessel flange.  These seals are available with or without bearing and can be provided with cooling jacket in case of high temperature.  Agitator seals are very cost effective & economical. These seals can be easily installed & repaired in the field to minimize cost and downtime.  Simple drive design that withstand shaft movement vibration & deflection.  Seal design eliminates the need of auxiliary equipment's for cooling and lubrication for mixer application.  We are experts in reconditioning all kinds of agitator seals are inherently balanced to take care of high pressure and vacuum.
